P6 HD led cross pharmacy sign advertising pharmacy cross led display outdoor 1200mm rgb pharmacy display shop sign
| Part number |
Value |
|
Pixel pitch |
6mm |
|
Pixel configuration |
1RGB(SMD2727) |
|
Pixel density |
40960 pixels for two sides |
|
Pixel resolution |
192×192dots |
|
Max brightness |
≥6000 CD |
|
View angle(horizontal) |
±60° |
|
Gray-scale |
256 grade |
|
Input voltage (AC) |
220V |
|
Work voltage (DC) |
5V |
|
Max power consumption |
1000W |
|
Average power consumption |
330W |
|
Scanning Mode |
1/8 |
|
Cooling way |
Natural cooling |
|
Control mode |
PC asynchronous control |
|
Communication mode |
WiFi / LAN / RF wireless communication (Optional) |
|
Support program |
animation, graphics, text, date, time, temperature, humidity |
|
Protection level |
IP65 |
|
MTBF |
1000h |
|
Life span |
100,000h |
|
Operation temperature |
－20～60℃ |
|
Operation humidity |
10%～90% |
|
Cabinet material |
Steel (cold rolled iron) |
|
Standard size |
1612(L) ×1200(H) ×100(T)mm |
|
Net weight |
58KG (Iron frame) |
|
Packing size |
1610(L) ×1370(H) ×210(T)mm |
|
Gross weight |
69KG (Iron frame) |
1) For outdoor usage, pour epoxy resin on the surface, full waterproof
2) Good quality with two side display, remote control board change the display shape.
3) Animations: all leds on, flashing, wave chasing
4) High bright LED for 100,000h
5) Input voltage: AC90-240V 50-60Hz,DC 5V
6) Power consumption:330W
7) Other colors, sizes and one side available!
1200mm full color pharmacy cross led design pharmacy cross led display outdoor
Features of LED Pharmacy Cross
1. waterproof, radiation proof
2. light weight, thin depth, front maintenance
3. low power consumption, high bright, easy installation
4. asynchronous control (RF/LAN/WIFI/RS232)
5. display content 2D/3D(animation, graphic, text, time, temperature)
Full color LED pharmacy sign IP65 cross LED display for church / hospital
Application
LED pharmacy cross is one kind of heteromorphic display consisting of LED cross modules and cross cabinet. The system combines with the technology of optics, microelectronics, information processing and transmission, mechanics and other technology etc. as a whole. The main application areas: the chemist's shop, pharmacy, drugstore, Apotheke, farmacia, church, hospital and crossroad.
1. We provide 2 years warranty. If the item is defective, please notify us within 7 days after goods delivered.
2. All items must be returned in their original condition, in order to qualify for a refund or exchange of goods.
3. The buyer is responsible for all shipping costs incurred.
4.Support 24 Hours Online Guide & Help if you have any problems!
5. High quality original LED Chip with CE,ROHS,FCC certified.
6. We gaurantee to test every part before the delivery and gaurantee the quality!
We are specilized in LED Display, which widely in industries of advertisement, pub, airport, station, harbor, gym, banks, school, factory, post office, department store, hospital, revenue office, customer, supervising centre, etc. All the products are exported to America, Russia, Great Britain, France, Austrilia, Greece, Italy, Japan, South Korea, Taiwan, Kazakhstan, etc.
Our company owns a group of high-quality professional and technical personnel and advanced modern sophisticated production equipment. We implement strict quality management, making every LED module,LED display cabinet,Power supply ,Video processor ,LED display into competitive products, etc. From the purchasing of the raw material to manufacturing, assembling, testing, we carry out every step one by one according to the ISO9001:2000 international quality control system strictly to guarantee the quality. And our products have passed the ISO14001:2004 international environment guarantee system certificate and European CE certification.
Q1: What's the warranty of your LED Display Screen ?
A1: We have a 2-year warranty for our led display screen, and 100,000 hours life span of the led lamps.
Q2: What about your pre-sale service and post-sale service?
A2: For pre-sale service: We have a professional sales team and 13 years technical team who are willing to answer your question. We can offer a whole complete solution for your project!
For post-sale service: We can instruct you how to use, adjust the screens, and change the broken modules with spare parts.
Also, we can send technicians to your country to solve problems.
Q3: Whats your payment term? How long it takes to delivery?
A3: We accept T/T, PayPal, West Union, L/C.... At least 30% deposit in advance, and the rest 70% before delivery.
Our average production time is 7-15 days, after receiving the deposit.
Q4: What's the control system?
A4: We usually use Nova, Linsn, Huidu, Colorlight, ONBON or XIXUN control system, and also we can make it as your requests.
Q5: How can you ensure the led display product quality?
A5: Our led display screen quality is our core competence, for 8 years, what we rely on.
We have each standard process to make quality products.
If any quality failures within warranty time, we will refund you on Alibaba.
